Flair Illume - Flair Illume aspires to be a leading lighting company by providing functional, aesthetic and revolutionary solutions to any lighting and luminary need so to spearhead trend-setting designs for all living and working spaces.

Folio Opal - Opal 10S / 10V / 10L

Opal 10S -> Rectangular luminaire with 17mm thickness. Guaranteed light homogeneity thanks to the laser-engraved methacrylate plate with Folio® Edge Lighting technology. Body in aluminium with opal diffuser. Available for multiple mounting options and customizable in size, shape and thickness.

Opal 10V -> Rectangular luminaire with 20mm thickness. Guaranteed light homogeneity thanks to the laser-engraved methacrylate plate with Folio® Edge Lighting technology. Body in aluminium with opal diffuser. Available for multiple mounting options and customizable in size, shape and thickness.

Opal 10L -> Rectangular luminaire with 19mm thickness. Guaranteed light homogeneity thanks to the laser-engraved methacrylate plate with Folio® Edge Lighting technology. Body in aluminium with opal diffuser. Available for multiple mounting options and customizable in size, shape and thickness.

Brand: Folio

Quantity

Download Brochure

Back to listing

Specifications
Features
Dimensions

Specifications

Opal 10S, Opal 10V & Opal 10L->

Lamp: LED MODULE

Wattage: 22W / 25W

Lumen: 2000lm / 2200lm

Color Temp. [K] 2700, 3000, 3500, 4000, 5700

TW[K]: 2700-5700

Features

Opal 10S, Opal 10V & Opal 10L->

Dimmability: 0-10V/ 1-10V/ DALI/ DMX/ Bluetooth/ PUSH

Aluminum finishes: Ox silver/ white/ black

Diffuser finishes: Matte opal/ glossy opal

Dimensions

Opal 10S ->

Thickness: 17 mm | 0.67 in

Weight: 24 kg/m² | 4.9 lbs/ft²

Opal 10V ->

Thickness: 20 mm | 0.79 in

Weight: 24 kg/m² | 4.9 lbs/ft²

Opal 10L ->

Thickness: 19 mm | 0.75 in

Weight: 24 kg/m² | 4.9 lbs/ft²
